In the last ten years, space organisations globally, along with new market players, have made it easier to access space for scientific and technological research. This movement towards making space more accessible has attracted a broader spectrum of scientists who were previously unaware of the possibilities for conducting experiments in space. This growing group includes experts from various fields such as biology, physiology, pharmaceutical chemistry, fluid physics, soft matter, and thermodynamics, although this list is far from complete.
However, many researchers from this broadened community may not completely grasp the intricate requirements for setting up and carrying out space experiments. CRESTLAB has been established to provide an extensive research platform to assist both academic and industrial sectors in designing, preparing, and performing benchmark experiments on Earth, which can then be modified for different space environments—whether it be in microgravity, lunar or Martian gravity, or hyper gravity.
CRESTLAB is structured around four specialized laboratories—Life Sciences, Material Sciences, Physical Sciences, and Data Science—along with two technical workshops. These facilities boast advanced instruments and support services that cover all phases of space experiment planning, from the initial engineering design and breadboard construction to early testing and data analysis.
Along with the technical support offered by our experts at CREST, here is a list of some major equipment available at CRESTLAB to help design space experiments:
Equipment
Brand: Thermo Scientific
Description: The Midi 40 CO₂ incubator is designed specifically for people who require a compact culturing workspace to handle small workloads.
The design features a heated inner glass door which prevents condensation, a non-porous silicon gasket maintains the chamber integrity. Units have a weldless stainless steel chamber for easy cleaning. This unit can be stacked because of its reinforced cabinet. The advanced IntrLogic™ II microprocessor has a bright digital display and intuitive touch pad for simplified entry of temperature, CO₂ and alarm data, with keyed set point switch to prevent unauthorised changes to the operating parameters. Unit has audible and visual alarm functions, precise and reliable CO₂ control featuring an accurate thermal conductivity sensor.
Brand: HOBERSAL
Description: HOBERSAL Furnaces For Metal and Ceramic 3d Printing Processes and Additive Manufacturing. Ceramic and metal Sintering, Annealing, debinding, fusing, curing. Works under vacuum and controlled atmosphere to ensure the sintered part is not contaminated by oxygen.
Applications:
Metals sintering: Debinding, sintering, stress-relieving, solution annealing and hardening
Ceramics, Glass, Composites, Sand sintering: Debinding, sintering, drying and curing
Plastics sintering: Curing, tempering, drying
Temperatures 1.150 ºC
Characteristics:
- Electronic-valve equipment to control gas atmosphere or/and vacuum.
- Eurotherm programmable controller equipment (10 programs/25 segments) with alarm (Over-heating Protection)
- Eurotherm programmable controller EPC Series and data logger software
- This system enables complete automatic electronic programming and controlling of the furnace chamber’s atmosphere, with automatic gas introduction, replacement and/or extraction.
Brand: RAISE3D
Description: Competitive and scalable; the Pro2 3D printer improves upon it’s award winning predecessor and provides the next generation of performance.
Characteristics:
- Electronic Driven, Dual Extrusion with Retracting Hot Ends; 4× Increased torque performance
- Massive Build Volume (12×12×11.8 inch / 305×305×300 mm)
- mm Layer Height
- Camera / HEPA Air Filtration
- Diverse Filament Compatibility (Up to 300℃)
- 32 Bit Motion Control Board
- 7-inch Touch Screen
- Resume Print after Power Loss or Filament Outage
- Wireless Compatibility
Brand: REGEMAT
Description: Microextrusion 3D bio-printer with included hot plate (temperature range -30°C to 250°C), and hot syringe (from 0°C to 50°C). UV light (365nm wavelength) pointer can be added to the printer for the UV crosslink of the bioink
Brand: ZIRBUS
Description: A modular system makes the laboratory freeze dryer perfectly suitable for a wide range of laboratory tasks. The housing is made of robust stainless steel. Different modules can be used with the basic unit, depending on the application. Environmentally friendly natural refrigerants are used.
Brand: TELSTAR
Description: FREEZE DRYER with condenser -85°C and 8 manifolds. Used to sublimate water to create aerogels and porous scaffolds
Brand: HERRICK PLASMA
Description: Oxygen plasma treatment to develop hydrophilic surface
Brand: VWR
Description: Drying ovens with forced air circulation, which are ideal for routine drying and heating applications when short drying times are required. Ovens feature adjustable ventilation by means of manually adjustable ventilation slide and 50 mm Ø exhaust duct at the rear of the unit.
Main characteristics:
- Microprocessor controller
- Integrated timer can be set for continuous mode or timer operation: 0 to 999 min or 0 to 99,9 h
- Over-temperature protection with visual alarm (Class 3.1 safety device)
- Temperature setting in increments of 1 °C
Brand: Reynier
Description: Horizontal Flow. UV Light HEROLAB NU-15 -254nm-365nm for sterylization process
Brand: HERAEUS
Description: Vacuum oven or vacuum drying cabinet from Heraeus, type VT 5042 EK. The oven door contains a vision window which can be used to check the laboratory samples and/or to read the internal temperature. Vacuum is applied by means of an external pump.
Nominal temperature: +250ºC
Capacity: 50 liters
Internal dimensions (W) x (D) x (H): 41 x 36,5 x 34 cm
Brand: SIGMA
Description: Centrifuge for 1mL Eppendorf with temperature control. Temperature range from -10°C to 40°C
Brand: KIMBALL PHYSICS
Description: Small Spot Collimated Beam, Alignment During Operation, Higher Current Option- up to 1 mA (100 eV to 10 keV)
Applications:
General Vacuum Physics Experiments
Space Physics Experiments
Specimen Heating
Electron Diffraction
Phosphor Studies
MBE RHEED Studies
Mounted Pneumatic Faraday Cup
Energy Range: 100 eV to 10 keV
Beam current / Spot size:
Standard: 10 nA to 100 µA / Standard: 0.5 mm to 25 mm
Small Spot option: 1 nA to 10 µA / 60 µm to 10 mm
High Current option: 1 µA to 1 mA / High Current option: 1.5 mm to 25 mm
Mounting: 2.75″ CF
The Kimball Physics EGG-3101 Electron Gun, with its matching EGPS-3101 Power Supply, is a multi-purpose modular Electron Gun with applications many areas. The EGG-3101 / EGPS-3101 is a complete subsystem ready to attach to a user’s vacuum system and turn on.
With a small spot option using a lanthanum hexaboride cathode, the gun can deliver spots down to 60 μm. With a high current option, beam currents up to 1 mA can be obtained.
The gun has the capability of producing a collimated small spot or a flood electron beam. Beam current, beam energy, and spot size are all independently adjustable over wide ranges. The energy can be varied from 100 eV to 10 keV. The beam current and spot size range depend on the system option as shown in the specifications table. Pulsing, beam blanking and rastering are also available as options.
The gun features an adjustable cathode feedthrough assembly that allows the mechanical alignment of the firing unit with respect to the anode and the column, in real time while the gun is operating at full voltage with beam on. The modular design of the EGG-3101 allows either the firing unit assembly or the lens assembly to be replaced by the user. The firing unit (including the cathode, cathode-mount, and Wehnelt aperture) is user-replaceable without removing the gun from the vacuum chamber. The anode is also easily replaceable. In addition, the cathode to anode spacing is internally adjustable to change the space charge effect or perveance of the electron beam.
Brand: YURI
Description: Desktop RPM controller that simulate altered gravity from 0.3g to 10g
Brand: LESKER
Description: Electropolished 18″ Standard Spherical Chamber for Ultra High Vacuum (10-8 mbar), equipped with over 10 ports for scientific instruments and 3 observation windows.
Description: This in-house-developed platform is composed of 3 independent 6.4 L reactors. Thermalization is ensured by double-wall external water circulation,side and top LED illumination and bottom air bubbling are enabling a reliable growth of algae among other species.
Description: This in-house-developed platform is composed of a controlled illumination and temperature to monitor plant development, from germination of seeds to full growth. Some area are fully isolated and remotely controlled with multiple sensors (light irradiation, CO2 level, % humidity, Temperature…) and equipped with remote watering.
Description: This workshop laboratory is equipped with every needed component to prepare and assemble experimental payloads for multiple platforms: Parabolic Flight, drop tower, sounding rocket…
Description: This laboratory is a room dedicated to simulation of lunar environment:
– sandy soil where remote-controlled mock rover can be operated.
– solar arch where illumination beam direction can be monitored to reproduce solar irradiation profile during specific missions.
Description: Our class ISO 7 clean room is presenting a superficie of 30m2. Fully equiped with a chemical hood and a laminar hood, the monitored environment (temperature, humidity, particles tracking) of the clean room is essential for all sensitive applications.
Brand: PRUSA /ULTIMAKER
Description: CREST Lab has currently 6 specimen of PRUSA 3D MK4 and 1 ULTIMAKER S3 printers mainly use for rapid prototyping of pieces or creation of experimental setup.
Technical Parameters
Build Volume 25×21×21 cm (9.84″×8.3″×8.3″)
Layer height 0.05 – 0.35 mm
Nozzle 0.4mm default, wide range of other diameters/nozzles supported
Filament diameter 1.75 mm
Supported materials Wide range of thermoplastics, including PLA, PETG, ASA, ABS, PC (Polycarbonate), CPE, PVA/BVOH, PVB, HIPS, PP (Polypropylene), Flex, nGen, Nylon, Carbon filled, Woodfill and other filled materials.
Max travel speed 200+ mm/s
Max nozzle temperature 300 °C
Max heatbed temperature 120 °C
Extruder Direct Drive, Bondtech gears, V6 hotend Print surface Removable magnetic steel sheets(*) with different surface finishes, heatbed with cold corners compensation
Brand: EPILOGLASER
Description: Epilog’s CO2 laser cutting machines provide a wide range of opportunities and possibilities. The versatility, speed, and precision of Epilog’s laser cutters are great assets for prototyping development and engineering support.
Laser machines can cut wood, paper, plastic, fabric, foam, and much more with such high precision and speed, giving lasers a clear advantage over other types of cutting technologies. Epilog’s laser systems are designed to be as easy to use as a paper printer, you can create a design in a graphic software program of your choice and print it directly to the laser cutting machine.
Features:
Work Area: 24″ x 12″ (610 x 305 mm)
Material Thickness: 5.5″ (140 mm)
Maximum Material Thickness with Table Removed:
8″ (203 mm) with a 23.5″ x 11.75″ (597 x 298 mm) engraving area.
Laser Tube Wattages:30 watts
Laser Source: State-of-the-art, digitally controlled, air-cooled CO2 laser tubes are fully modular, permanently aligned and field replaceable.
Intelligent Memory Capacity: Multiple file storage up to 64 MB. Rolling buffer allows files of any size to be engraved.
Air Assist: Attach an air compressor to our included Air Assist to remove heat and combustible gases from the cutting surface by directing a constant stream of compressed air across the cutting surface.
Laser Dashboard: The Laser Dashboard™ controls your Epilog Laser’s settings from a wide range of software packages – from design programs to spreadsheet applications to CAD drawing packages.
Red Dot Pointer: Since the laser beam is invisible, the Red Dot Pointer on Epilog’s Mini and Helix Lasers allows you to have a visual reference for locating where the laser will fire.
Relocatable Home: When engraving items that are not easily placed at the top corner of the laser, you can set a new home position by hand with the convenient Movable Home Position feature on the Legend Series Lasers.
Operating Modes: Optimized raster, vector or combined modes.
Motion Control System: High-speed, continuous-loop, DC servo motors using linear and rotary encoder technology for precise positioning.
X-Axis Bearings: Ground and polished stainless steel NeverWear Bearing System.
Resolution: User controlled from 75 to 1200 DPI.
Speed and Power Control: Computer or manually control speed and power in 1% increments to 100%. Vector color mapping links speed, power and focus to any RGB color. Print Interface: 10 Base-T Ethernet or USB Connection. Compatible with Windows® XP/Vista/7/8/10.
Brand: TABER
Description: The TABER® Oscillating Abrasion Tester – Model 6160 is best known as an “oscillating sand tester”. Described in ASTM F735 (Standard Test Method for Abrasion Resistance of Transparent Plastics and Coatings Using the Oscillating Sand Method), the oscillating sand tester is used to measure the relative abrasion resistance of a material to surface abrasion and / or marring. The primary application of the Oscillating Sand Abrasion Tester is for transparent materials and coatings utilized in windows and lenses, but it might also be used to evaluate organic paints & coatings, plastics, metals and other materials.
Abradants
- Reference abradant in ASTM F735 in a quartz silica sand, graded 6/9. Besides the silica abrasive media, other potential abradants include alumina (zirconia), silicon carbide, aluminum oxide and glass bead. For repeatable test results, the sizing and shape of the abradant is absolutely critical.
- During testing, the abradant may become ‘worn’ as the sharp edges contact the specimen and other abrasive particles. To ensure reproducibility, new abrasive media should be used for each test. It is also recommended that the abrasive be replaced after 300 cycles for longer cycle tests.
Evaluation
- Using a haze meter, the haze and light transmission of a transparent test specimen is measured and recorded. After subjecting the specimen to the specified number of abrasion cycles, the results are measured as a change in haze and light transmission. Abrasion resistance for opaque materials is measured visually or by weight loss.
Brand: ADVACAM
Description: A miniaturized and low-power radiation camera equipped with particle tracking and imaging detector Timepix3 (256 x 256 square pixels with a pitch of 55 μm). MiniPIX TPX3 detector with 500 µm thick Si sensor, MiniPIX EDU TPX camera with 300/500 µm Si thick sensor.
Brand: Teledyne Flir
Description: High-Performance Thermal Camera with Viewfinder. The FLIR T840 infrared camera is designed to help thermography professionals. Thanks to an integrated eyepiece viewfinder and a bright 4-inch color LCD display, the T840 makes it easy to conduct inspections outside in bright, challenging light conditions. Pair the T840 with a FLIR FlexView™ dual field of view lens for the convenience to instantly switch from wide-area to telephoto scanning. A 6° telephoto lens option is also available to ensure accurate temperature measurement of small targets from farther distances
Brand: ANTON PAAR
Description: Cora 5001 is a Raman analyzer for the quick and reliable identification of substances based on their chemical fingerprint, or for the monitoring of chemical changes. Choose the Fiber model for flexible analysis outside the instrument via a probe or the Direct model which analyzes samples in a closed compartment and is certified as laser class 1 – for ultra-safe use. The guided analysis procedure means Cora 5001 is suitable for operation with only minimal training. The small footprint and battery option make these benchtop Raman instruments versatile tools for analytical tasks in-house or in the field. Excitation Dual Wavelenght: 532 nm and 785nm.
Brand: ANDOR
Description: Andor BC 43 Benchtop Confocal Microscope. Including 2x objective and joystick for motorized sample positioning. Equipped with: Brightfield and Differential Phase Contrast transmitted white light illumination, widefield epifluorescence for low-light imaging and patented Borealis™-illuminated multipoint confocal for fast high-contrast 2D & 3D imaging. Includes built-in vibration management, dual function Focus Seek and Lock™. Excitation lines 405nm, 488nm, 561nm & 638nm, and emission filters for commonly used fluorophores such as DAPI, GFP, mCherry, CY5. 4.1 MP (6.5µm pixel, 16-bit) sCMOS camera up to 82% QE. 18.4 mm field of view. Workstation: 10 Core, 18M Cache, 2.8GHz up to 4.9GHz; 64GB RAM; 512GB SSD Boot drive; 8GB Graphics card, 2TB Data storage; Windows 10 operating system. Software: Fusion BC43 acquisition software for multi-dimensional experiments in 2D, 3D, time series, multi-field, multi-well and large area montage with image stitching. Renders 3D images in real-time as a volume. Includes ClearView GPU™ for enhanced resolution images with reduced sample background. Imaris Quant for high-quality snapshots, movie creation, isosurface reconstructions, 2D point-to-point measurement and Imaris Arena for image management.
Lens 10x and 20x
Brand: KRUSS
Description: The Bubble Pressure Tensiometer – BP100 measures dynamic surface tension with high accuracy. It reliably analyzes the mobility of surfactants, thus enabling high-speed processes such as spraying, coating, printing, and cleaning to be optimized. The instrument covers a wide speed range as part of a single, fully automatic measuring process. This enables you to find out how quickly a surfactant acts and when the required surface tension has been reached. In this way, the BP100 assists in the development, selection, and dosing of surfactants optimized for your process.
Brand: 3P Instruments
Description: 2 parallel stations surface area and mesopore analyzer, 4-pressure transducer configuration, with in situ degassing 3P sync 200 and Controller and heating mantle up to 400°C
Brand: 3P Instruments
Description: The 3P densi is a compact and automated density analyzer for powders and solids as well as for the characterization of foamed materials. By use of these pycnometers, the sample gets filled in the sample cell; sample preparation takes place in continuous or pulsed gas flow or optionally under vacuum. The rinsing, measurement and possible repeat measurement are operated automatically. Repeat measurements optionally are effected either by presetting a user specified tolerance (auto-stop) or a user specified number of runs.
Brand: ANTON PAAR
Description: Fast one-hand coupling and decoupling of measuring geometries in just one second – operating temperatures (-160 °C to 1000 °C)
Precisely measure even low-viscosity samples with high sensitivity (from 7.5 nNm to 2 nNm). Stable results even for long-term measurements with low torque: include thermal management trimming mirror for a 360° view of the sample with no blind spots, which avoids sample preparation errors and leads to highly reproducible results.
Detection of any sample behavior change , Reproducible duration of each measuring point down to 1 ms
Full pharma compliance: RheoCompass software (21 CFR Part 11, full data integrity according to ALCOA+)
Brand: HOT DISK
Description: Multi-purpose, highly performing R&D thermal conductivity meter is designed for precision analysis of thermal transport properties of materials of all types: solids, liquids, powders, and pastes. It is frequently used in automated production line QC testing. The TPS 2500 S handles sub-millimeter-thick bulk samples, has a Thermal Conductivity range of 0.005 to 1800 W/m/K, and accommodates temperatures from cryogenic to 1000°C. It can also analyze the anisotropic thermal transport properties of uniaxial materials. The TPS 2500 S is a capital research instrument, meets ISO 22007-2 and is CE marked.
Brand: JASCO
Description: It obtains an infrared spectrum of absorption or emission of a solid, liquid, or gas. It measures how much light a sample absorbs at each wavelength and so to convert this data to analyze the internal bond of the sample
Brand: LEICA
Description: The Leica S6 D digital stereo microscope comes complete with an HDMI / USB output high definition camera. Either way this camera can output USB to a computer or HDMI to any monitor. The screen attached provides and all in one streamlined design. When using the camera with HDMI output on board software pops up and is controlled by the mouse. You can adjust the camera settings and capture images / videos and choose to play them back. The microscope itself provides high resolution images with its world-renowned Leica optics. With the included 10x/23mm eyepieces this system has a 6.3x – 4x zoom range and 110mm working distance.
Brand: NIKON
Description: Provided with 10x, 20x, 40x lens magnifications. Epifluorescence attachment (wavelength 385nm, 475nm, 550nm, 621nm) with a monochrome camera
Brand: SHIMADZU
Description: The Nano Particle size analyzer SALD 7500 Nano is capable of continuously measuring changes in particle size and particle size distribution at one-second intervals, within a range spanning 7 nm to 800 μm. In addition, unique options that accommodate the measurement of even high-concentration samples (up to 20 wt%) and trace quantity samples (down to 15 μL) are available. Due to its leading-edge measurement capabilities, the analyzer will likely be used for many applications in new areas, including nanotechnology, the life sciences, and fine bubbles (microscopic bubbles).
Brand: SHIMADZU
Description: The UV-3600i Plus UV-Vis-NIR spectrophotometer incorporates the latest technology in optical components to achieve high sensitivity, high resolution, and an ultra-low stray light level, leading the way to new solutions. Measurement capability in the UV, Visible and up to 3,300nm in the near-IR region allows for characterizing all types of samples, including solids, powders, wafers, films and liquids. Applications include, but are not limited to, haze analysis, band gap analysis, photovoltaics, coatings, and optical component characterization.
The UV-3600i Plus is equipped with double grating monochromators to achieve ultra-low stray light levels that ensure constant optical resolution of 0.1nm or lower in the ultraviolet and visible region and 0.4nm in the near-infrared region. The wavelength range spans from 185nm to 3,300 nm making, this spectrophotometer suitable for all kinds of samples, especially samples encountered in the field of materials that absorb or reflect in the ultraviolet, visible and near-infrared regions. Main researches and markets utilizing this instrument include materials characterization in electronics and optics, chemicals, pharmaceuticals, cosmetics, life sciences, environmental, textiles and food.
Shimadzu’s LabSolutions UV-Vis control software is included with the instrument. Measurement modes include photometric, spectrum, quantitation, kinetics, time course and bio-methods. Advanced software add-ons for Film Thickness Measurement, Color Measurement, UPF (Ultraviolet Protection Factor) Calculation and Daylight Transmission Measurement are available. A large sample compartment for larger solid samples, integrating spheres and variable angle measurement accessories are also available.
150 mm Dia. Integrating Sphere Attachments
ISR-1503 (BaSO4) is used to measure the reflectance spectra of solid samples, such as powders, paper, or fabrics, or the transmittance spectra of liquid or solid samples. It enables reliable measurements unaffected by factors such as the sample surface status. Also, low-noise near infrared region measurements can be obtained by using a Spectralon ISR-1503F attachment.
- Wavelength range: 200 to 2500 nm
- Integrating sphere I.D.: 150 mm
- Detectors: PMT, InGaAs, PbS
- Sample placement orientation: Lateral for transmittance and 0° reflectance, Vertical for 8° reflectance
- Incident light angle: 0° or 8°
- Opening rate: 4.0% (0° reflectance), 4.0% (8° reflectance), or 2.9% (transmittance)
Brand: Amersham Biosciences
Description: The Ultrospec 4300 pro is designed for high resolution scanning for assessment of impurities in sample preparations with bandwidth of less than 1.8 nm.
Specifications:
- Wavelength Range: 190-1100 nm, in 0.1nm steps
- Scanning Speed: 6200 nm/minute maximum, 1 nm step
- Monochromator: Concave grating with 1200 lines/mm
- Wavelength calibration: Automatic upon switch-on
- Spectral bandwidth: < 1.8nm
- Wavelength accuracy: ± 0.7nm
- Wavelength reproducibility: ± 0.2nm
- Light sources: Tungsten halogen and deuterium arc
- Detector: Single solid state silicon photodiode
- Photometric range: – 3.000 to + 3.000 A, 0.01 to 99999 concentration units, 0.1 to 200 %T
- Photometric linearity: ± 0.5% or ± 0.003 A to 3.000 A at 546nm, whichever is the greater
- Photometric reproducibility: Within 0.5% of absorbance value to 3.000A (at 546nm)
- Stray light typically: <0.025%T at 220nm using NaI, <0.025%T at 340nm using NaNO2
- Stability Warm Up: ± 0.001A/h at 340 nm at 0A after
- Noise: ± 0.001A near 0A and ± 0.002A near 2A at 546 nm
- Sample compartment size: 5.5″ W x 8.6″ D x 3.4″ H(14 x 22 x 8 cm)
Brand: KRUSS
Description: The Standard configuration of the DSA30 Drop Shape Analyzer is designed for the semi-automatic measurement of the static and dynamic contact angle and the scientific assessment of wettability by means of the surface free energy (SFE). The instrument is well-suitable for the reliable quality assurance of surface pre-treatment processes as well as the development and optimization of wetting and coating procedures.
Tasks and applications
- Characterization of surface pre-treatment processes
- Investigation of the adhesion and stability in bonding and coating processes
- Checking the wettability of plastic, glass, ceramic, wood, or metal
- Validating surface cleanliness
- Measuring methods and options
- Contact angle between a liquid and a solid
- Surface free energy from contact angles of several test liquids using all common models
- Static contact angle, advancing angle, and receding angle
- Surface tension and liquid-liquid interfacial tension using pendant drop or constrained sessile drop
Brand: SHIMADZU
Description: Load cell from 10N to 10kN. Universal tester for bending, tensile and compression test. Tensile test on dogbone shape specimen, compression and bending test grips diameter is 10cm.
Brand : KEYENCE
Description: Objectives Magnification x20 – x2000.
Analyze and inspect various objects with several dimensions. It is connected to a monitor for image analysis (e.g., nanoparticles dimensions…)
